Bussmann 60710 Bussmann MDA Cartridge Slow Blow Time Delay Fuse Without Indicator, 250 VAC/125 VDC, 30 A

Bussmann MDA Cartridge Slow Blow Time Delay Fuse Without Indicator, 250 VAC/125 VDC, 30 A

SKU: 589264
$ 6.87 / ea
Save 18% · Retail: $8.40

Exception ocurred: "file_put_contents(../resources/views/storeblade/product_pricing_leadtime.blade.php): failed to open stream: Permission denied"!   Available to Ship in 4-5 weeks




Ships From Price Qty
Austin Texas Warehouse
Ships in 5-7 Days
$6.87/ea 4
Sikeston Missouri Warehouse
Ships in 5-7 Days
$6.87/ea 10
Order From Manufacturer
Available to Ship in 4-5 weeks
$6.87/ea ∞

About the Bussmann MDA Cartridge Slow Blow Time Delay Fuse Without Indicator, 250 VAC/125 VDC, 30 A

Bussmann MDA Cartridge Slow Blow Time Delay Fuse Without Indicator, 250 VAC/125 VDC, 30 A

Amperage: 30 amps
Mpn # 60710
Shipping Dimensions 8.8" x 4.8" x 3.5"
Weight 1.10 lbs.
  • Series: MDA
  • Type: Cartridge, Slow Blow
  • Amperage Rating: 30 A
  • Voltage Rating: 250 VAC/125 VDC
  • Interrupt Rating: 1500 A at 250 VAC, 10 kA at 125 VAC/VDC
  • Response Time: 60 min at 135%, 120 sec at 200%
  • Terminal: Ferrule
  • Body Style: Non-Rejection Cylindrical
  • Element: Single
  • Material: Ceramic Tube
  • Diameter: 1/4 in
  • Length: 1-1/4 in
  • Standards: UL Listed, CSA Certified, RoHS Complaint
  • Usage: For Electronic Circuits
  • Nickel-plated brass end cap construction
  • Nominal resistance: 0.002465 ohm
  • Optional axial leads available
  • Ceramic body allows for higher amp/volt rating combinations
  • Interrupting ratings for 63 mA - 6 A were measured at 70 % - 80% power factor on AC. The interrupting ratings for 7 A - 15 A were measured at 100 % power factor on AC
  • DC cold resistance (measured at <10% of rated current)
  • Voltage drop was measured at 20 deg C ambient temperature at rated current
