Bussmann S501 Cartridge Fast Acting Fuse Without Indicator, 250 VAC, 1.25 A, 1500 A

SKU: 589266

$7.07/ea
Save 13% · Retail: $8.09

In Stock and Ready to Ship




Ships From Price Qty
Texas Warehouse
Ships in 4-6 days
$7.07/ea 9
Order From Manufacturer
Available to Ship in 4-5 weeks
$7.07/ea

About the Bussmann 60717

Bussmann S501 Cartridge Fast Acting Fuse Without Indicator, 250 VAC, 1.25 A, 1500 A

Product Details

Mpn # 60717
Shipping Dimensions 8.8" x 4.8" x 3.5"
Shipping Dimensional Weight 0.84 lbs.

Product Features

  • Series: S501
  • Type: Cartridge
  • Amperage Rating: 1.25 A
  • Voltage Rating: 250 VAC
  • Interrupt Rating: 1500 A
  • Terminal: Ferrule
  • Body Style: Non-Rejection Cylindrical
  • Element: Single
  • Material: Ceramic Tube
  • Diameter: 5 mm
  • Length: 20 mm
  • Standards: cURus Recognized, CSA Certified, SEMKO, VDE, IMQ, CCC Approved
  • Usage: For Electronic Circuits
  • Nickel-plated brass end cap construction
  • Nominal resistance: 0.176 ohm
  • Optional axial leads available
  • Silver-plated end cap construction (50 mA-400 mA)
  • Fast-acting for maximum protection
  • High break capacity for use in higher fault energy electronic circuitry
  • Voltage drop was measured at 20 deg C ambient temperature at rated current
