Ads Arc 24 Leachfield Chamber - Ads 2412BD Septic Leaching Chamber

SKU: 39402
   based on 2 Reviews
100% recommend this product
$29.06/ea
Cargo Shipping Only
Save 51% · Retail: $59.72

In Stock and Ready to Ship
More Buying Options


Ships From Price Qty
Spring Valley Nevada Warehouse
Ships in 4-6 days
$29.06/ea 60
Order From Manufacturer
Available to Ship in 1-2 weeks
$29.06/ea

About the ADS 2412BD

This 2412BD ARC 24 Type Septic Leaching Chamber is a genuine part manufactured by (ADS) Advanced Drainage Systems. It has dimensions of 67" L (repeat length is 60") x 22.5" W  x 12" H and is about 11.2 square feet (nominal). This Leaching Chamber has a capacity of 5.02 cubic feet and is specially designed and perforated to be the perfect component for pipe and gravel leaching field systems. The Arc 24 leaching chamber features an open bottom (total area of 7.96 sq. ft.) for leach capabilities, a solid top for quick and easy burying, and louvered sidewalls (7.5" high) to minimize soil intrusion and add strength. These sections conveniently interlock using an integral modified post and dome joint that allows for both straight line installation and slightly radial applications as well.

Weighing only 13 lbs, this ADS Arc 24 Septic Leaching Chamber can be quickly installed by one person and include inspection vent ports with easy-to-remove knockouts for maximum job site flexibility. It shall meet the load rating of H-10 (16,000 lb per axle) with a minimum of 12 inches of cover when tested in accordance with IAPMO PS 63 and installed in accordance with manufacturers installation procedures. Universal inlet/outlet end caps are available for professional and long-lasting connections to both gravity-fed and pressure-dosed septic systems. You are going to need the ADS 2402BD end cap (sold separately) to go along with this tank. If you will need a splash plate, that would be the ADS 0068BD (sold separately).

How many feet of line do you need? Many factors play a role in choosing the correct amount of measurement required for a home including estimated water usage, number of and even soil type. Installing and designing your septic system also depends on your State and Local codes. It would be best for you to contact a local septic system contractor who could do a site inspection and would be able to give a better assessment of what it would take to build an efficient septic system.

Product Details

Product: Leaching Chamber
Manufacturer: ADS
Style: Leach Chamber (Bio-Diffuser)
Color: Black
Height: 12"
Mpn # 2412BD
Shipping Dimensions 60.0" x 24.0" x 12.0"
Weight 12.15 lbs.

Product Videos

Arc Leachfield Chamber Installation

Product Features

  • Injectionmolded from High Density Polyethylene (HDPE) for lightweight and sturdy design
  • 20degree integral articulating joint that is ideal for either straight or contoured septic leachfield applications
  • True corrugated chamber design eliminates flat surfaces and provides increased load bearing capability in the trench
  • Lock and Drop joint provides a more positive connection during installation and backfill
  • Inspection vent ports on every unit with easytoremove knockouts for maximum job site flexibility
  • Convenient fivefoot lengths are easy to handle
  • Diamond plate texture increases slip resistance and enhances ease of installation
  • Side Port Coupler snaps in place to allow side entry at any joint throughout the trench line
  • Will need the ADS 2402BD end cap
  • Capacity: 5.02 cu ft
  • Length: 67"
  • Repeat Length: 60"
  • Sidewall Height: 7.5"
  • Overall Height: 12"
  • Overall Width: 22.5"
  • Weight: 13 lbs.
  • Pallet Quantity: 120 chambers
  • Van (Box Trailer) Quantity: 17 pallets
  • Flatbed Quantity: 15 pallets
  • Total Open Bottom Area: 7.96 sq. ft.
  • Nominal dimension in square feet: 11.2

Reviews

Rated 5 out of 5 based on 2 reviews


General Contractor - Florida Rated 5 by Keith Dove
  Yes, I recommend this product.
This Leaching Chamber is the only way to properly install a drain field in the more crowded surburban areas in which most of us live. Instead of having a 4" pipe surrounded with gravel or sand with only small holes randomly scattered about the pipe with the 24" Arc Leaching Chamber now you have the entire 24" times the lenght of the drain field where the more affluent that runs out of the tank the more of the chamber is used. In addition because the open part of the Arc Chamber is facing down you also have the added benefit of gravity assisting with the percolation of the liquid into the soil. I have been using these Chambers since their inception will NEVER go back to the old and inefficient wrapped drain field pipe. The ARC Chamber System is Great also because it costs me one fifth the labor to install as conventional systems and the Chamber System is much less expensive than hauling load after load of gravel. You cannot lose with this system no matter how hard you might try. Keith Dove, Founder and CEO, Atlanta Dove Construction, Southeastern U.S. Technical, Ebro, Florida 32437
Originally posted on plumbersstock.com Feb/2017


 Rated 5 by John o.
Great product easy to work with
Originally posted on PlumbersStock May/2019
