Elkay ELUH3520LDBG Gourmet (Lustertone) Stainless Steel Double Bowl Sink Package

SKU: 80656
Save 53% · Retail: $1,398.00

See buying options below:

Ships From Price Qty
Tennessee Warehouse
Ships in 1-3 Days
$663.31/ea 2
California Warehouse
Ships in 1-3 Days
$663.31/ea 1
NewYork Warehouse
Ships in 1-3 Days
$679.06/ea 1
Iowa Warehouse
Ships in 1-3 Days
$873.75/ea 1
Order From Manufacturer
Available to Ship in 2-3 weeks

About the Elkay ELUH3520LDBG

The Elkay ELUH3520LDBG, a Gourmet product, is a stainless steel single bowl sink package. This rectangular nickel-bearing stainless steel sink is designed for an under mount installation. The sink is furnished with the LKWOBG2018SS bottom grid and the LK99 drain. This Elkay ELUH3520LDBG Double Bowl Sink is from the Gourmet (Lustertone) Collection, designed for efficiency and functionality. ELUH sinks have been re-designed to accommodate 1/2” reveal and no-reveal installation options. Its overall dimensions are 35-1/4" in length with 20-1/2" in width and 9-7/8” in depth. The left bowl is 11-1/2" long, 16" wide and 7-7/8" deep while the right bowl is 20" long, 18" wide and 9-7/8" deep. This sink has no faucet hole. The 3-1/2” drain openings are located at the rear center of each bowl (refer to the specification sheet). The exposed surfaces of this #18-gauge sink have been polished to a lustrous highlighted satin finish. The underside has the patented Sound Guard for sound deadening and to prevent condensation. This Elkay ELUH3520LDBG Gourmet (Lustertone) Sink complies with ASME A112.19.3/ CSA B45.4 and is listed by the International Association of Plumbing and Mechanical Officials as meeting the requirements of the Uniform Plumbing Code and the National Plumbing Code of Canada. Made in the USA and covered by a Limited Lifetime Warranty by Elkay, a trusted leader in the industry.

Product Details

Manufacturer: Elkay
Material: Stainless Steel
Style: Large/ Small Bowl
Product Collection: Gourmet
Type: Sink
Room: Kitchen
Material Gauge: 18 Gauge
Other Info: Drain Included
Shape: Rectangle
Use: General use
Depth: 7" up to 8" Deep
Mount Type: Under Mount
Mpn # ELUH3520LDBG
Shipping Dimensions 26.4" x 45.0" x 14.2"
Weight 34.00 lbs.
Shipping Dimensional Weight 95.70 lbs.

Product Features

  • Highest quality sink formed of #18 gauge stainless steel.
  • Type 304 nickel bearing stainless steel.
  • Under mount.
  • Requires a minimum of 39 cabinet size.
  • Each sink is furnished complete with a bottom grid LKWOBG2018SS and a Drain LK99.
  • Bowl Depth: the large bowl is 9-7/8 inches and the small bowl is 7-7/8 inches.
  • Exposed surfaces are hand blended to a lustrous highlighted satin finish.
  • Fully protected by Sound Guard undercoating to dampen sound and prevent condensation.
  • Drain Opening: 3-1/2 inches.
  • The L in the product designation indicates that the large bowl is on the right and the small bowl is on the left.
  • This undermount sink is designed to affix to the underside of any solid surface countertop.
  • The sink complies with ASME A112.19.3/ CSA B45.4.
  • This sink is listed by IAPMO as meeting the applicable requirements of the Uniform Plumbing Code, International Plumbing Code, and National Plumbing Code of Canada.
  • Optional Accessories: Bottom Grid (LKWOBG1116SS), Cutting Board (CBS1418 with a sink reveal required for proper fit), Faucet (LKGT1041 or LKGT2041), Hardware (LKUCLIP8 with 2 required), Rinsing Basket (LKWRB2018SS, LKWERBSS or LKWRB1116SS), Sinkmate (LKSM17, LKSMHOOK, LKSMSPONGE or LKSMHSL) and Soap Dispenser (LKGT1054).
