Honeywell CSP-O-A300-001/U Adjustable Current Switch

SKU: 373007

$56.49/ea
Save 57% · Retail: $130.67

  Available to Ship in 4-5 weeks


Ships From Price Qty
Order From Manufacturer
Available to Ship in 4-5 weeks
$56.49/ea

About the Honeywell CSP-O-A300-001

Honeywell CSP-O-A300-001/U Adjustable Current Switch. All of these sensors have a solid-state output with an adjustable or fixed trip point (setpoint). These current switches should be used in applications in which a inGo/No Going current switch is required. The current switches can be used to monitor devices with a maximum continuous operating current of up to 250 Amps. These current switches do not need to be externally powered, since the power for the switch is induced from the conductor being monitored. The split core switches are ideal for retrofit or existing installations, since it is not necessary to power down the unit and disconnect any wires during the installation process. Solid core switches are extremely easy to install, they are an excellent choice for new installations.

Product Details

Manufacturer: Honeywell
Type:
Style: Switch
Installation Type:
Product:
Mpn # CSP-O-A300-001
Weight 0.69 lbs.

Product Features

  • Great for monitoring fans, pumps, motors, compressors, or other electrical equipment
  • 5 F to 104 F
  • -15 C to 40 C
  • UL94-5V/Burgundy
  • Split
  • continuous--200 Amps: for 6 seconds--400 Amps: for 1 second--800 Amps
  • N.O.
  • 0.30 Amps @ 200 Vac/Vdc
  • 2200 Vac
  • 3.0-200 Amps
  • Designed for easy maintenance and Teflon coating prevents mineral build-up and extends life
  • 2 45/64 in. high x 3 21/64 in. wide x 1 5/64 in. deep
  • 3/4 in. (19 mm). Accepts up to 350 MCM (17.3 mm) cables.
  • RoHS-Directive 2002/95/EC, WEEE-Directive 2002/96/EC
  • 600 Vac
  • 1-3/8 in.
  • 35 mm
  • 0-250A
  • 69 mm high x 85 mm wide x 25 mm deep
  • 0.23 lb
  • 0.1 kg
  • 40 Hz to 1 kHz
  • Approved
  • 0 to 95% RH, non-condensing
  • Induced from monitored conductor
