Honeywell M6410A3017 Honeywell M6410A3017 Globe Valve Actuator

Honeywell M6410A3017 Globe Valve Actuator

SKU: 374310

This product is not currently available for purchase.

About the Honeywell M6410A3017 Globe Valve Actuator

Honeywell M6410A3017 Globe Valve Actuator. Cartridge Globe Valve Actuators are small electric Actuators for individual room control that provide Floating or modulating control of Two-Way or Three-Way Valves.

Product: Globe
  Actuator
Manufacturer: Honeywell
Mpn # M6410A3017
Weight 6.05 lbs.
  • HVAC
  • Threads onto V58XX valve bonnet
  • 50 Hz; 60 Hz
  • Flammability Rating UL94V-5V
  • Plenum-rated cable
  • 5 to 95% RH
  • 24 Vac +10%, -30%
  • Driving-- 0.7 VA
  • -40 F to +158 F
  • -40 C to +70 C
  • 32 F to 122 F
  • 2 3/8 in. high x 1 15/16 in. wide x 3 15/16 in. deep
  • 0 C to 50 C
  • IP42,Class I Insulation (24 Vac)
  • 0
  • 130 C Maximum
  • 266 F Maximum
  • Valve
  • SPDT; Two position; Floating
  • Stays in place
  • 67.5 lbf
  • 300 N
  • 61 mm high x 49 mm wide x 100 mm deep
  • No
  • 1/4 in.
  • 6 mm
  • Threaded conduit connector
  • Driving @ 60 Hz (sec)-- 125 sec
  • None (use valve dust cap)
  • 1/2 in. conduit hub
  • 1 inch to 1-1/2 inch V58XX Globe Valves
  • 0.3125 lb
  • 0.15 kg
  • Low Maintenance Plastic Housing
  • High force for metal-seated valves
