Honeywell ML4135A1007/U HVAC Fast-Acting, Two-Position Actuator

SKU: 374399

$122.95/ea
Save 63% · Retail: $336.31

  Available to Ship in 4-5 weeks


Ships From Price Qty
Order From Manufacturer
Available to Ship in 4-5 weeks
$122.95/ea

About the Honeywell ML4135A1007

Honeywell ML4135A1007/U HVAC Fast-Acting, Two-Position Actuator. Honeywell ML4135 are Fast-Acting, Two-Position Actuators, with spring return, Direct Coupled Actuators (DCA) and feature an integral junction box for on/off damper controls

Product Details

Product: Actuator
Manufacturer: Honeywell
Style: Parts
Mpn # ML4135A1007

Product Features

  • HVAC
  • 60 Hz
  • UL873, Plenum Rated
  • Two color-coded leads
  • 5 to 95% RH, non-condensing
  • Driving-- 0.18A, 18W, Holding-- 0.11A, 9W
  • -40 F to +140 F
  • -18 C to +60 C
  • cUL C22.2 No. 24-93
  • -40 F to +130 F
  • 7.5 in high x 5.13 in wide x 3.32 in deep
  • -18 C to +55 C
  • NEMA 1
  • 0
  • Driving (dB(A) @ 1m)-- 65; Holding (dB(A) @ 1m)-- 20 (no audible noise)
  • Totally enclosed Micro Switch snap-acting switch
  • 3/8 to 1/2 in. square or round
  • Damper
  • Two position; SPST
  • Spring Return
  • 40 lb-in.
  • 192 mm high x 129 mm wide x 84 mm deep
  • 4.5 Nm
  • Maximum Stall-- 150 lb-in.
  • Maximum Stall-- 17 Nm
  • Yes, 32003532-005
  • Driving @ 60 Hz-- 20 sec, 25 sec maximum
  • Maximum-- 15 sec
  • Aluminum Hub, four set screws
  • 10 to 13 mm square/round
  • CCW
  • 16 in.
  • Mounting bracket, ground screw
  • 406 mm
  • 6 lb
  • 2.72 kg
  • Aluminum housing
  • Integral junction box with three 7/8 in. conduit openings (fittings not included)
  • Direct Coupled
