Honeywell ML4135B1006/U HVAC Fast-Acting, Two-Position Actuator

Name: Honeywell ML4135B1006/U HVAC Fast-Acting, Two-Position Actuator
Brand: Honeywell
SKU: 374400

SKU: 374400

We are Sorry we no longer carry this item.

Check below for similar items!

About the Honeywell ML4135B1006

About the Honeywell ML4135B1006/U HVAC Fast-Acting, Two-Position Actuator

Honeywell ML4135B1006/U HVAC Fast-Acting, Two-Position Actuator. Honeywell ML4135 are Fast-Acting, Two-Position Actuators, with spring return, Direct Coupled Actuators (DCA) and feature an integral junction box for on/off damper controls

Product Details

Product:	Actuator
Manufacturer:	Honeywell
Style:	Parts
Mpn #	ML4135B1006
Weight	1.55 lbs.

Product Features

HVAC
60 Hz
UL873, Plenum Rated
Two color-coded leads
5 to 95% RH, non-condensing
Fluid-filled element operates SPST, Micro Switch snap-acting switch.
Driving-- 0.18A, 18W, Holding-- 0.11A, 9W
-40 F to +140 F
-18 C to +60 C
cUL C22.2 No. 24-93
-40 F to +130 F
7.5 in high x 5.13 in wide x 3.32 in deep
-18 C to +55 C
NEMA 1
0
Driving (dB(A) @ 1m)-- 65; Holding (dB(A) @ 1m)-- 20 (no audible noise)
Fluid-filled element operates SPST, Micro Switch snap-acting switch
3/8 to 1/2 in. square or round
Damper
Two position; SPST
Spring Return
40 lb-in.
192 mm high x 129 mm wide x 84 mm deep
4.5 Nm
Maximum Stall-- 150 lb-in.
Maximum Stall-- 17 Nm
Yes, 32003532-005
Driving @ 60 Hz-- 20 sec, 25 sec maximum
Maximum-- 15 sec
Aluminum Hub, four set screws
10 to 13 mm square/round
CW
16 in.
Mounting bracket, ground screw
406 mm
6 lb
2.72 kg
Aluminum housing
Integral junction box with three 7/8 in. conduit openings (fittings not included)
Direct Coupled
