Honeywell RP471A1002/U Wall or Panel Mounted Pneumatic Relay

SKU: 375917

Save 61% · Retail: $136.59

In Stock and Ready to Ship

Ships From Price Qty
Massachusetts Warehouse
Ships in 1-4 Days
$54.43/ea 4
Illinois Warehouse
Ships in 4-6 Days
$54.43/ea 21
Order From Manufacturer
Available to Ship in 3-4 weeks

About the Honeywell RP471A1002

Honeywell RP471A1002/U Wall or Panel Mounted Pneumatic Relay. The four port, snap acting relay, converts a proportional air pressure change, from a controller to a positive (two-position) pressure change. It can also divert a supply line to one of two branches.

Product Details

Manufacturer: Honeywell
Style: Pneumatic
Mpn # RP471A1002
Weight 1.03 lbs.

Product Features

  • Pneumatic, four-port, snap acting relay
  • 5 to 95% RH
  • 1 psi maximum
  • 7 kPa maximum
  • Barb fittings 5/32 in. (4 mm) O.D. plastic tubing
  • 0.039 scfm at 1 psi differential (18 mL/s at 5 kPa differential)
  • Adjustable between 3 to 15 psi
  • Adjustable between 21 to 103 kPa
  • Proportional to 2-position converter
  • 0.5 psi
  • 3 kPa
  • 1 1/2 in. diameter x 2 3/4 in. deep
  • 38 mm diameter x 70 mm deep
  • 30 psi, maximum
  • 205 kPa, maximum
  • 0 F to 140 F
  • -18 C to +60 C
  • 14003030-001, 1 1/2 in. Mounting Clip for Mounting relay to wall or panel
  • Wall or Panel
