Honeywell TH146-N-U Low Volt Non-Programmable 3H/1C Conventional and 4H/2C Heat pump Thermostat

SKU: 376363

$626.68/ea
Save 59% · Retail: $1,542.57

  Available to Ship in 4-5 weeks


Ships From Price Qty
Order From Manufacturer
Available to Ship in 4-5 weeks
$626.68/ea

About the Honeywell TH146-N-U

Honeywell TH146-N-U Low Volt Non-Programmable 3H/1C Conventional and 4H/2C Heat Pump Thermostat. This Thermostat features a 2-wire user console connection, idea for retrofits. This TH164-N-U includes a Non-Programmable console, a control module, and an outdoor temperature sensor

Product Details

Product:
Manufacturer: Honeywell
Type: Pumps
Mpn # TH146-N-U
Weight 0.90 lbs.

Product Features

  • ApplicationHeat/Cool or Heat Pump with Auxiliary Heat
  • 3 heat/cool conventional 4 heat/2 cool heat pump thermostat features a 2-wire user console connection, ideal for retrofits
  • Installer mode bypasses compressor lockout delay for quicker installations
  • Removable connector strip simplifies wiring
  • Selectable cycles (2 to 6 per hour) optimize system to heating/cooling application
  • Control module for equipment connections can be installed near furnace/air handler, only 2 wires required for console connection
  • Automatic changeover between heating and cooling
  • Backlit console display shows indoor and outdoor temperature, or indoor temperature and humidity level
  • Complete defrost sequence protection (requires AC146-410 air duct temperature sensor)
  • Keypad lock for console prevents tampering
  • StagesUp to 3 Heat/3 Cool Conventional; Up to 4 Heat/2 Cool Heat Pump
  • Operating Humidity Range (% RH) is up to 0% to 95%, non-condensing
  • Switch Positions (System) is HEAT-OFF-COOL-AUTO-EM.HEAT
  • The Power Method s Hardwired
  • Setting Temperature Range is (F) 40 F to 86 F
  • Setting Temperature Range is (C) 5 C to 30 C
  • Cycles per Hour is 2-6 CPH (Heating and Cooling)
  • Includes a non-programmable console, a control module, and an outdoor temperature sensor
