Honeywell V5011A1767 Honeywell V5011A1767/U 2-Way 3

Honeywell V5011A1767/U 2-Way 3" Flanged Globe Valve

SKU: 376617

This product is not currently available for purchase.

About the Honeywell V5011A1767/U 2-Way 3" Flanged Globe Valve

Honeywell V5011A1767/U 2-Way 3" Flanged Globe Valve. This Valve is powered by a Q5001/Modutrol IV Motor, and also features a stainless steel stem valve. Valve Dimensions are 13-1/2" by 7-1/2" by 11" deep. This valve is used for proportional level control of hot nor cooled water and glycol solutions. This Honeywell V5011A1767/U 2-Way 3" Flanged Globe Valve has an equal percentage flow type. It is a Pneumatic Valve that operates with actuators which specifically direct the functions of the valve in two position control. Honeywell Company is one of the world’s leading Company in HVAC Industry. Their expertise in manufacturing technologies with their excellent performance has made them a well known, and trusted name.

Product: Globe
Style: 2 Way
Connection Type: Flanged
Manufacturer: Honeywell
Mpn # V5011A1767
Weight 2.60 lbs.
  • Mixing or diverting models
  • Two-way operation
  • Spring-loaded, self-adjusting packing
  • 13 1/2 in. high x 7 1/2 in. wide x 11 in. deep (342 mm high x 190 mm wide x 279 mm deep)
  • For Quiet Water Service--20 psid (For Quiet Water Service--138 kPa)
  • Globe Valve Construction/Design
  • Chilled or hot water with up to 50% Glycol or Low pressure steam. Not for use with fuels.
  • Cast Iron Valve Body
  • 316 Stainless Steel
  • Equal Percentage
  • Meets ANSI 125 Standard
  • Teflon Cone
  • 150 psi at 240 F water; 15 psi steam
  • 1034 kPa at 115 C water; 100 kPa steam
  • ML6984/ML7984; ML7420/ML7421A/ML7425; ML6420,21A,25; Q5001/Modutrol IV Motor; MP953
  • 40 F to 250 F (4 C to 121 C)
  • Flanged Connections
