The Honeywell V5011B1070/U 2-Way 6 inch Flanged Globe Valve

SKU: 376623

 Free Shipping!
Save 58% · Retail: $24,063.33

In Stock and Ready to Ship

Ships From Price Qty
Massachusetts Warehouse
Ships in 1-4 Days
$10,140.72/ea 2
Illinois Warehouse
Ships in 4-6 Days
$10,140.72/ea 1
Order From Manufacturer
Available to Ship in 3-4 weeks

About the Honeywell V5011B1070

The Honeywell V5011B1070/U 2-Way 6 inch Flanged Globe Valve. This valve is made with Bronze body with female, screwed-end connections or cast iron body with flanged-end connections. It is a Mixing or diverting valve with stainless steel stem with serviceable Teflon packing.and replaceable seats. It has a Constant total flow throughout full plug travel and a spring loaded, self-adjusting packing. This Honeywell V5011B1070/U 2-Way 6 inch Flanged Globe Valve also provide proportional or two-position control of hot or chilled water in heating or cooling systems. This Valve utilizes direct mounting valve actuators, Q5020/Q5022 linkages with Direct Coupled Actuators, or Pneumatic Valve Actuators to operate the valve. It can be used for mixing service (V5013B and F) to direct flow from one of two inlets to a common outlet or for diverting service (V5013C) to direct flow from a common inlet to one of two outlets. The Honeywell V5011B1070/U 2-Way 6 inch Flanged Globe Valve is a Class IV (0.01% of Cv) leakage rating and is suitable for pneumatic or electronic actuation. Honeywell is the global leader in HVAC (heating, Ventilation, Air Conditioning) product. Honeywell invents and manufactures product for the HVAC industry. . They have the world class products and services and solutions that work in million homes, buildings, and hundreds of gas and electric utilities worldwide

Product Details

Product: Globe
Manufacturer: Honeywell
Style: 2 Way
Color: Blue
Connection Type: Flanged
Mpn # V5011B1070
Shipping Dimensions 16.0" x 11.0" x 20.0"
Weight 3.60 lbs.
Shipping Dimensional Weight 19.96 lbs.

Product Features

  • Mixing or diverting models.
  • Spring-loaded
  • self-adjusting packing
  • flanged end connections
  • ANSI Class 125 and Class 250 cast iron bodies
  • Valves utilize direct mounting valve actuators
  • Sizes range from 2-1/2 to 6 inches.
  • Stainless steel stem with serviceable Teflon packing.
  • Equal Percentage flow characteristic.
  • Valve Type: Globe Valve
  • Body Pattern: Two-way
  • Flow Characteristic: Equal Percentage
  • Controlled Medium: Chilled or hot water with up to 50% Glycol
  • Low pressure steam
  • Max. Safe Operating Pressure: 150 psi at 240 F water or 15 psi steam
  • ANSI/ASME Rating: 125
  • Maximum Differential for Quiet Water Service (psi): 25 psid
  • Static Pressure Rating: ANSI 125
  • Ambient Temperature Rating: 40 F to 250 F
  • Materials (Body): Cast Iron
  • Materials (Seat): Bronze
  • Materials (stem) Stainless Steel
  • Used with: Q5001/Modutrol IV Motor; MP953; ML6420
  • 21A
  • 25; ML7420/ML7421A/ML7425; ML6984/ML7984
