Honeywell VBN3FN3P0X Three-Way Female NPT Actuated Control Ball Valve

Product Features

• Sizes from 1/2 to 2-1/2 inches with internal (female) NPT connections.
• Field configurable for normally open or normally closed fail-safe position.
• Removable manual operating handle to control valve during installation or in an event of power failure.
• ANSI Class IV seat leakage specification (0.01% of Cv).
• Optional NEMA 3R (IP54) rated enclosure for outdoor applications.
• Actuator can be mounted on the valve in any of four positions.
• Wide Cv choices from 0.33 to 109.
• Valve installs in a globe valve "T" pattern, no extra elbows or piping required.
• Field-serviceable stem assembly.
• Nickel-chrome plated brass ball and stem.
• Mixing or Diverting control.
• Equal percentage or linear flow characteristics.
• Reduced B-port Cv for constant loop flow.
• Choice of four, factory-installed actuation control schemes: Floating, Modulating (2-10 V), Spring Return 2-Position, Spring Return Modulating/Floating.
