Honeywell VGF21ES50 2-Way 5 inch Standard Model Flanged Globe Valve.

SKU: 379716

 Free Shipping!
Save 58% · Retail: $3,797.44

In Stock and Ready to Ship

Ships From Price Qty
Illinois Warehouse
Ships in 4-6 Days
$1,604.41/ea 1
Order From Manufacturer
Available to Ship in 3-4 weeks

About the Honeywell VGF21ES50

Honeywell VGF21ES50 2-Way 5 inch Standard Model Flanged Globe Valve. This valve is an ANSI class 125 cast iron bodies with flanged end connections. It is used for 2-position or modulating control of steam, hot water, or chilled water-glycol solutions up to 50 percent concentration, in closed loop heating, ventilation and air conditioning (HVAC) systems. This valve also has an accurate positioning with equal percentage and linear flow characteristics to ensure precise temperature control. It is made of stainless steel trim standard for long life span. This Honeywell VGF21ES50 2-Way 5 inch Standard Model Flanged Globe Valve has a self-adjusting packing, steam inlet pressure up to 125 psig and 353 F maximum temperatures. It is a universal bonnet for direct-coupled electric and pneumatic actuators for easy mounting, or linkage coupled modutrolâ„¢ motors and MN/MS series direct coupled actuators. Honeywell VGF21ES50 2-Way 5 inch Standard Model Flanged Globe Valve has a face-to-face flange dimensions per ANSI/ISA S75.03 standard and a constant total flow throughout full plug travel (3-way bodies). It offers best in class size, Cv range and close-off pressure, and a precise control for any application. Honeywell is the global leader in HVAC (heating, Ventilation, Air Conditioning) product. Honeywell invents and manufactures product for the HVAC industry. They have the world class products and services and solutions that work in million homes, buildings, and hundreds of gas and electric utilities worldwide

Product Details

Product: Globe
Manufacturer: Honeywell
Style: 2 Way
Connection Type: Flanged
Trade Tools: HVAC
Use: Water
Electrical Voltage: 24 Volt
Mpn # VGF21ES50
Shipping Dimensions 15.0" x 10.0" x 12.0"
Weight 45.75 lbs.

Product Features

  • 15-3/4 in. lenght x 10 in. width x 12-3/8 in. height
  • DN125
  • -7 C to +120 C, steam 180 C
  • 20 F to 250 F, steam 353 F
  • 1-7/8 in.
  • 13 psi
  • 90 kPa
  • 285 Cv
  • 244 kvs
  • Stem down to close
  • Globe Valve
  • 400 mm lenght x 254 mm width x 314 mm height
  • Chilled or hot water with up to 50% Glycol or Steam. Not for use with fuels.
  • Cast Iron ASTM A126 Class B
  • Stainless Steel
  • Equal Percentage
  • Must be purchased separately
  • Meets ANSI 125 Standard
  • 125
  • 1 1/2 in.
  • 38 mm
  • 47.6 mm
  • 175 psig
  • Spring-loaded PTFE cone rings
  • 0.05% of Cv
  • 1206 kappa
  • ML6421B; ML7421B; Q5001/Modutrol IV Motor; MP953
  • Direct acting
  • Flanged
  • Two-way
  • 5 in.
