Honeywell VGF21LS60 Honeywell VGF21LS60 2-Way Flanged GlobeMixing Valve, 6 Inch

Honeywell VGF21LS60 2-Way Flanged GlobeMixing Valve, 6 Inch

SKU: 379727

This product is not currently available for purchase.

About the Honeywell VGF21LS60 2-Way Flanged GlobeMixing Valve, 6 Inch

The Honeywell VGF21LS60 3-Way Flanged Globe/Mixing Valve is made of the durable Cast Iron body. One of the great features of this valve is its ability to accurately ensure precise temperature control. The Honeywell VGF21LS60 3-Way 2 1/2 Mixing Flange Globe Valve, features a universal bonnet and pneumatic actuators, for easier mounting, and for linkage coupled modutrolâ„¢ motors as well as MN/MS series direct coupled actuators. This Honeywell VGF21LS60 3-Way Flanged Globe/Mixing Valve produces constant flow throughout full plug travel (3-way bodies), and offers best in class size, CV range and close-off pressure, with precise control for both water and steam. The metal to metal seating gives it longer life span and it has the ability to demote seat leakage with field configurable for safety purposes. This Flanged Globe/Mixing Valve is a certified original product of Honeywell. Honeywell is the global leader and master in HVAC (heating, Ventilation, Air Conditioning) products.

** Due to this product's considerable weight and size our current shipping costs could fluctuate. Please call 435-868-4020 for today's shipping rates.

Product: Globe
Style: 2 Way
Trade Tool Type: HVAC
Use: Water
Electrical Voltage: 24 Volt
Manufacturer: Honeywell
Connection Type: Flanged
Mpn # VGF21LS60
Weight 258.00 lbs.
  • 17-3/4 in. lenght x 11 in. width x 12-3/8 in. height
  • DN150
  • -7 C to +120 C, steam 180 C
  • 20 F to 250 F, steam 353 F
  • 1-7/8 in.
  • 13 psi
  • 90 kPa
  • 370 Cv
  • 317 kvs
  • Stem down to close
  • Globe Valve
  • 451 mm lenght x 279 mm width x 314 mm height
  • Chilled or hot water with up to 50% Glycol or Steam. Not for use with fuels.
  • Cast Iron ASTM A126 Class B
  • Stainless Steel
  • Linear
  • Must be purchased separately
  • Meets ANSI 125 Standard
  • 125
  • 1 1/2 in.
  • 38 mm
  • 47.6 mm
  • 175 psig
  • Spring-loaded PTFE cone rings
  • 0.05% of Cv
  • 1206 kappa
  • ML6421B; ML7421B; Q5001/Modutrol IV Motor; MP953
  • Direct acting
  • Flanged
  • Two-way
  • 6 in.
