The Honeywell VGF31EM30 3-Way Flanged Globe/Mixing Valve, 3 Inch

SKU: 379734

Cargo Shipping Only
Save 58% · Retail: $1,756.69

  Available to Ship in 3-4 weeks

Ships From Price Qty
Order From Manufacturer
Available to Ship in 3-4 weeks

About the Honeywell VGF31EM30

The Honeywell VGF31EM30 3-Way Flanged Globe/Mixing Valve is made of the durable Cast Iron body. One of the great features of this valve is its ability to accurately ensure precise temperature control. The Honeywell VGF31EM30 3-Way 2 1/2 Mixing Flange Globe Valve, features a universal bonnet and pneumatic actuators, for easier mounting, and for linkage coupled modutrolâ„¢ motors as well as MN/MS series direct coupled actuators. This Honeywell VGF31EM30 3-Way Flanged Globe/Mixing Valve produces constant flow throughout full plug travel (3-way bodies), and offers best in class size, CV range and close-off pressure, with precise control for both water and steam. The metal to metal seating gives it longer life span and it has the ability to demote seat leakage with field configurable for safety purposes. This Flanged Globe/Mixing Valve is a certified original product of Honeywell. Honeywell is the global leader and master in HVAC (heating, Ventilation, Air Conditioning) products.

Product Details

Product: Globe
Manufacturer: Honeywell
Style: 3 Way
Trade Tools: HVAC
Use: Water
Connection Type: Flanged
Electrical Voltage: 24 Volt
Mpn # VGF31EM30
Weight 178.00 lbs.

Product Features

  • 11-3/4 in. lenght x 7-1/2 in. width x 12-3/4in.H
  • DN80
  • -7 C to +120 C
  • 20 F to 250 F
  • 1-3/8 in.
  • 58 psi
  • 400 kPa
  • 115 Cv
  • 99 kvs
  • Mixing, step up to close A-AB
  • Globe Valve
  • 298 mm lenght x 191 mm width x 322 mm height
  • Chilled or hot water with up to 50% Glycol. Not for use with steam or fuels.
  • Cast Iron ASTM A126 Class B
  • Stainless Steel
  • Equal Percentage (A-AB)
  • Must be purchased separately
  • Meets ANSI 125 Standard
  • 125
  • 3/4 in.
  • 20 mm
  • 35 mm
  • 175 psig at 130 F (66 C)
  • Spring-loaded PTFE cone rings
  • Port A seat leakage: 0.5%; Port B seat leakage 1.0%; For Supply mixing control; use diverting value for boiler/chiller bypass
  • 1206 kPa at 66 C (130 F)
  • ML6984/ML7984; ML6420/21A/25; ML7420/21A/25; Q5020/DCA; Q5001/Modutrol IV Motor; MP953
  • Stem up to close A-AB
  • Flanged
  • Three-way
  • 3 in.
