Metal-Fab 5M12 Type B Round Chimney Pipe Length - 5 Inch x 12 Inch

SKU: 204360
   based on 1 Reviews
$6.66/ea
Save 65% · Retail: $18.99

In Stock and Ready to Ship!
More Buying Options


Ships From Price Qty
Nevada Warehouse
Ships in 3-4 Days
$6.66/ea 2
Order From Manufacturer
Available to Ship in 4-5 weeks
$6.66/ea

Product Details

Length: 12
Manufacturer: Metal-Fab
Product: Vents and Terminations
Use: Commercial & Industrial
Mpn # 5M12
Weight 1.50 lbs.

Product Features

  • Class B Gas vent pipe for furnaces; unit, wall and water heaters.
  • Elimination of sharp edges by hemming the flue and casing.
  • Incorporates features that make installation quick, easy, and safe.
  • Easy assembly and disassembly, without tools, using positive twist lock.
  • 360 degree rotation of small diameter fittings using swivel tees, wyes, and elbows.
  • Saves space inside standard stud walls using oval pipe.
  • Operates with a non-positive vent static pressure.
  • Enables the product to be used in homes and commercial buildings at close clearance to combustible.
  • Listed by Underwriters Laboratories for use with approved category 1 gas furnaces, heaters, and boilers.
  • Effectively vents Category: appliances such as gas-fired fireplaces, furnaces, water heaters, and boilers
  • .018" galvanized steel outer wall and .012" aluminum alloy inner wall
  • 1/4" insulating air space
  • Double-wall design allows a 1" clearance to combustibles
  • SureLock locking system creates secure connections without tools
  • Hemmed flue and casing eliminate sharp edges
  • Compatible with other brands of 5" UL Listed round gas vent pipe (see list below)
  • Listed to UL 441
  • Limited one-year warranty
  • Approximate Dimensions: 5" inner diameter x 12" L
  • Please Note: Pipe overlaps 1.5" when joined together. Therefore, the assembled length is 1.5" less than listed.
