Panasonic FV-07VBB1 EcoVent Universal Contractor Motor & Grille Assembly

SKU: 461829
$52.48/ea Free Shipping!
Save 10% · Retail: $58.30

See buying options below:

Ships From Price Qty
California Warehouse
Ships in 1-3 Days
$52.79/ea 69
Order From Manufacturer
Available to Ship in 2-3 weeks

About the Panasonic FV-07VBB1

The Panasonic FV-07VBB1 Universal-Can (U-Can) 4-Pack motor/grille assembly helps contractors assemble cost-effective and powerful EcoVent fans. The contractor packs of these ENERGY STAR rated bathroom fans allow contractors to receive the housing and the motor/grille components separately. The benefit of this is that the risk of losing or damaging vital installation components is reduced. Each pack contains 4 sets of the motor and grille assembly. Panasonic's EcoVent fans have Veri-Boost integral switch technology, which provides the necessary airflow requirements for ASHRAE 62.2, ENERGY STAR 3.0 for homes, CA Title 24, CalGreen and many other green building standards. These bathroom fans also feature a smaller grille design than comparable energy-efficient fans. This makes them easier to integrate into any room's decor. The Panasonic FV-07VBA1 fan housing companion to this contractor pack is needed to make a complete bathroom fan.

Product Details

Type: Vent Fan
Color: White
Style: Fan Kit
Manufacturer: Panasonic
Mount Type: Ceiling Mount
Other Info: In Stock
Shape: Rectangle
Use: A/C Only
Mpn # FV-07VBB1
Weight 10.00 lbs.

Product Features

  • MAX. Current(amps): 0.25
  • Power Rating (V/Hz): 120/60
  • Motor Type: AC
  • Type of Motor Bearing: Ball
  • Thermal Fuse Protection: Yes
  • Blower Wheel Type: Sirocco
  • ENERGY STAR Qualified: Yes
  • Duct Diameter (Inches): 4
  • Mounting Opening (Inches sq.): 7 7/8
  • Grille Size (Inches sq.): 9 1/2
  • Housing Depth (Inches sq.): 4 3/4
  • Gross Weight (lbs): 5.7
  • UL tub/Shower Enclosure: Yes
  • Washington VIAQ Code: Yes
  • California Title 24 Compliant: Yes
  • Mfg in ISO 9001 Certified Facility: Yes
  • This order is for the motor/grill assembly of the EcoVent Universal-Can (U-Can) contractor pack
  • Ideal for new residential construction
  • 70 CFM, cost effective ENERGY STAR solution 1.1 sones at 0.1" w.g. (56 CFM/1.4 sones @ 0.25" w.g.)
  • Unique Veri-Boost integral switch ensures the fan meets designed airflow requirements
  • Provides Ventilation Verification Assurance: 50 CFM Installed Performance
  • Small grille design complements the aesthetics of your bathroom, powder room or laundry room
  • Housing and motor/grille packaged separately; reduces risk of parts being lost or damaged onsite
  • 4" duct adaptor
  • Built-in metal flange provides blocking for penetrations through drywall as an air barrier, and assists with the decrease in leakage in the building envelope during blower door testing
  • UL listed for tub/shower enclosure when used with a GFCI protected circuit
  • Can be used to comply with ASHRAE 62.2, LEED and ENERGY STAR for Homes 3.0
  • 70 CFM, cost effective ENERGY STAR solution 1.1 sones at 0.1
  • Provides Ventilation Verification Assurance: ?50 CFM Installed Performance
  • 4
