Rain Bird RBLC24WG1 Pump Start Relay

SKU: 244083
Save 46% · Retail: $539.26

   Available to Ship in 2-3 weeks

Ships From Price Qty
Order From Manufacturer
Available to Ship in 2-3 weeks

About the Rainbird RBLC24WG1

This pump start relay is part of the pump protection system that monitors your irrigation system to protect the pump from damage due to low pressure. It monitors the pressure through the use of a pressure sensor located on the discharge side of the pump. At the beginning, or anytime during a zone cycle, if the water is not available, the pressure will drop within the pump and the pressure sensor will signal a time delay to begin counting. If the pressure has not recovered over the timer cycle, the pump shuts down to save itself before damage occurs, and resets automatically on the next cycle.

Product Details

Product: Timers and Clocks
Manufacturer: Rainbird
Type: Pump Relay
Style: Relay
Mpn # RBLC24WG1
Shipping Dimensions 7.8" x 10.0" x 6.8"
Weight 6.80 lbs.

Product Features

  • 40 AMP certified relay
  • 4-wire color coded wiring for easy installation
  • Grounding Provision
  • Completely automatic pump protection
  • Adjustable time delay
  • Bridges the gap between 24 VAC lawn controllers and 110/220V pump motors
  • One model works for all pumps from 3/4 hp to 5 hp
  • Low pressure sensor protects the pump if the inlet water flow is restricted, reduced, or completely blocked
  • Housed in NEMA 3R weathertight enclosures with "baked-on" powder coating for long life in difficult environments
