About the Shoemaker 936-0-8X8

This White 8" x 8" Shoemaker 936-0 Series Vent Cover is designed to fit and cover an 8" wide by 8" high opening. Shoemaker has a complete line of products designed for homes, offices, stores, and many other commercial applications. The quality and simplicity of this fixed blade grille are only two of the many reasons why Shoemaker Manufacturing leads the field in innovative air-grille design for real world applications. The Shoemaker 936-0 Series Steel Blade Grille with 45° Fixed Blade is designed with rigid steel louvers at 45° that are parallel to the shortest dimension, allowing a minimal view of the air duct. The Shoemaker 936-0 Series vent cover comes with a recessed screwdriver-operated opposed blade damper. It is used to regulate the airflow through linked sections of adjacent blades that rotate in the opposite direction. Compared to other damper types, an opposed blade damper maintains a more even airflow. It also provides better control over the airflow in all operating positions. A recessed screwdriver-operated damper prevents any unnecessary adjustments of the damper setting. The Shoemaker 936-0 Series Steel Blade Grille with 45° Fixed Blade can be ordered with "F" Torx center pin tamper-proof screws for added security. Be sure to measure the hole opening size instead of measuring the face plate of your old grille. This grille is designed to fit over an 8" x 8" existing hole or duct. Refer to the Specification Sheet for more information.

Product Details

Product: Vents and Terminations
Manufacturer: Shoemaker
Use: Ducting and Venting
Mpn # 936-0-8X8
Weight 2.56 lbs.

Product Features

  • Optional tamper-proof screws are available
  • Optional square to round ADC compliant 2 inches No Labor Collar with roll formed retention bead, available in square sizes only (936-NLC)
  • 936-O recessed screwdriver operated opposed blade damper
  • 45 degrees fixed blade
  • Surface mount grille
  • Blades parallel to shortest dimension
  • Countersunk mounting holes for flush appearance with color matching Phillips posi-drive screws
  • Standard color is soft white
