Please make sure you understand the item and the dimensions before ordering.
By Clicking "Add to Cart", you acknowledge that this product is not eligible for returns
Product Details
Amperage:
500 amp
Mpn #
60691
Shipping Dimensions
8.8" x
4.8" x
3.5"
Weight
1.10 lbs.
About the Bussmann 60691
About the Bussmann GMA Cartridge Fast Acting Fuse With Indicator, 250 VAC, 500 mA
Bussmann GMA Cartridge Fast Acting Fuse With Indicator, 250 VAC, 500 mA
Product Features
Series: GMA
Type: Cartridge
Amperage Rating: 500 mA
Voltage Rating: 250 VAC
Interrupt Rating: 35 A at 250 VAC, 10 kA at 125 VAC
Response Time: 60 min at 135%, 2 min at 200%
Terminal: Ferrule
Body Style: Non-Rejection Cylindrical
Element: Single
Material: Glass Tube
Diameter: 5 mm
Length: 20 mm
Standards: UL Listed, CSA Certified, PSE Approved
Usage: For Electronic Circuits
Nickel-plated brass end cap construction
Nominal resistance: 0.454 ohm
Optional axial leads available
Fast-acting, low breaking capacity
Interrupting ratings for 63 mA - 6 A were measured at 70 % - 80% power factor on AC. The interrupting ratings for 7 A - 15 A were measured at 100 % power factor on AC
DC cold resistance (measured at <10% of rated current)
Voltage drop was measured at 20 deg C ambient temperature at rated current
