Rainbird PCT07 RAINBIRD PCT07 X73007 PRESSURE-COMPENSATING BUBBLER 1/2

RAINBIRD PCT07 X73007 PRESSURE-COMPENSATING BUBBLER 1/2" FPT 7 GPH

SKU: 163598
$ 3.66 / ea

Exception ocurred: "file_put_contents(../resources/views/storeblade/product_pricing_leadtime.blade.php): failed to open stream: Permission denied"! In Stock and Ready to Ship


Ships From Price Qty
Order From Manufacturer
Available to Ship in 2-3 weeks
$3.66/ea ∞
Free Sprinkler Design

About the RAINBIRD PCT07 X73007 PRESSURE-COMPENSATING BUBBLER 1/2" FPT 7 GPH

RAINBIRD PCT07 X73007 Compensating Bubblers are ideal for a variety of applications including shrub plantings, trees, containers, annual color, and flower beds. Rain Bird's new pressure compensating bubblers are designed for a rugged environment. Offered in 5 gph, 7 gph, and 10 gph models, the bubbler style outlet and medium-flow options provide more flexibility for commercial applications. The 1/2" FPT threaded inlet makes these devices ideal for installations using a PVC pipe and schedule 80 risers.

Product: Bubbler
Use: Drip
Manufacturer: Rainbird
Connection Type: FPT
Mpn # PCT07
Weight 1.00 lbs.
  • Point-Source Medium-Flow Emitters for Watering Larger Shrubs and Trees
  • • Xeri-Pop spray head with fitting • UNI-Spray or shrub adapter • Inlet Colors: Light Brown, Violet, Green
  • Color: Violet
  • Flow Rate: 7 gph (26.50 l/h)
  • The Pressure Compensating Bubblers shall feature a heavy-duty low-maintenance design and be made of UV resistant material.
  • They require filtration of 100 mesh (150 micron).
  • They shall be pressure compensating. The models shall flow at 5gph, 7gph, and 10 gph when inlet pressure is between 15 to 50 psi (1.03 to 3.45 bar.)
  • The inlet shall be a 1/2" FPT.
  • The Pressure Compensating Bubblers shall be manufactured by Rain Bird Corporation, in Mexico.
  • Use as a bubbler on 1/2" PVC riser
  • 1/2" FPT threads screw onto a variety of risers, spray heads, and fittings, delivering point-source, pressure compensating flow
  • Robust design - durable plastic construction is UV-resistant and color coded caps identify flow rate
  • Uniform flow throughout a wide pressure range (15 to 50 psi; 1.03 to 3.45 bar)
  • Flow rates: 5 to 10 gph (18.93 to 37.85 l/h)
  • Pressure: 15 to 50 psi (1.03 to 3.45 bar)
  • Required Filtration: 100 mesh (150 micron)
  • Inlet: 1/2" FPT threads are specifically designed to be used with: • 1/2" PVC risers, schedule 80 risers • MDCF50MPT 1/2" MPT compression fittings (16-18mm) • XFDMA050 1/2" MPT insert fittings (17mm) • Rain Bird 1800 Series spray head with fitting
