Toro EHC-01-01 Toro EHC-01-01 Electric-Hydraulic Converter, 1-Station, Normally Open
View 2 of Toro EHC-01-01 Toro EHC-01-01 Electric-Hydraulic Converter, 1-Station, Normally Open
View 3 of Toro EHC-01-01 Toro EHC-01-01 Electric-Hydraulic Converter, 1-Station, Normally Open

Product Options

Toro EHC-01-01 Electric-Hydraulic Converter, 1-Station, Normally Open

SKU: 507454
$ 78.12 / ea
Save 42% · Retail: $134.00

Exception ocurred: "file_put_contents(../resources/views/storeblade/product_pricing_leadtime.blade.php): failed to open stream: Permission denied"!   Available to Ship in 2-3 weeks


Ships From Price Qty
Order From Manufacturer
Available to Ship in 2-3 weeks
$78.12/ea

About the Toro EHC-01-01 Electric-Hydraulic Converter, 1-Station, Normally Open

This Toro EHC-01-01 electric-hydraulic converter is designed for 1 station with normally-open valves. Expanding the system is easy and unlimited: You can add as many converters as needed. The Toro EHC-01-01 converts the electrical output from sophisticated, flexible electric controllers to pressure-based signals in hydraulic irrigation systems. With direct manual control, you can activate any sprinkler from the converter. If a single converter unit needs to be replaced, it can be easily done without affecting other converters.

Toro electric-hydraulic converters are perfect for retrofitting hydraulic systems to allow the operation of normally-open or normally-closed hydraulic valves with a 24-VAC controller. Hydraulic control valves are ideal for new installations in locations with increased lightning risk and poor water conditions. This Toro EHC-01-01 electric-hydraulic converter for 1 station with normally-open valves has a 2-year warranty.

Manufacturer: Toro Irrigation
Product: Hydraulic Unit
Color: Black and White
Style: Single Station
Electrical Voltage: 24 Volt
Wire Size: 18 AWG
Amperage: 0.30 amps
Height: 8.8"
Width: 4-1/2"
Depth: 2-1/2''
Mpn # EHC-01-01
Weight 1.00 lbs.
  • Supplied pre-plumbed with in-line filter on inlet supply line, pre-assembled on sturdy plastic mounting plate
  • Ideal for areas with high lightning risk and poor water conditions
  • Direct manual control activates any sprinkler from the converter
  • Unlimited expansion: Add as many converters as needed
  • Any single converter unit can be replaced easily without affecting other converters
  • Available for normally-open or normally-closed hydraulic systems
  • Normally open: Valve elevation should not exceed 25' (7.6 m) above or 70' (21.3 m) below controller elevation
  • Normally closed: Valve elevation should not exceed 0' above or 70' (21.3 m) below controller elevation
  • Pressure: 40-150 psi (3.0-10.3 Bar)
  • Wiring: 18 AWG x 4' (1.2 m) wire leads with maximum distance from converter to valve: 3/16" (5 mm) - 500' (15 m) and 1/4" (6 mm) - 1000' (30 m)
  • Electrical input power: 24 VAC (60 Hz); Holding - .225A @ 24 VAC; Inrush - .400A @ 24 VAC
  • Can be mounted to a wall or pedestal in a plastic cabinet
  • Warranty: 2 years
