HONEYWELL AM102-1 1" AQUAMIX MIXING VALVE 100-145F FIP

About the HONEYWELL AM102-1 1" AQUAMIX MIXING VALVE 100-145F FIP

THERMOSTATIC; 1 INCH NOMINAL SIZE; 1 INCH NPT X 1 INCH NPT END CONNECTION; 3.3 INCH END TO END DISTANCE; 2.7 INCH BASE TO INLET DIMENSION; 2.7 INCH INLET TO MIXING OUTLET DIMENSION; NICKEL PLATED BRASS, EPDM O-RING BODY MATERIAL; 16 GPM FLOW RATE; 212 DEG F TEMPERATURE RATING; 150 PSI PRESSURE RATING; APPLICATION AUTOMATIC FAUCET, COMBO SYSTEM, DOMESTIC WATER, GREEN HOUSE, HEAT PUMP SYSTEM, INDUSTRIAL, NURSING HOME, PHOTO PROCESSING, PUBLIC FACILITIES, RADIANT FLOOR HEATING, SOLAR HOT WATER, SPACE HEATING; ASSE 1017/1070/1016T, IAPMO, CSA, UPC STANDARDS; AM-1 MODEL; WEIGHT 1.6 LB
