Honeywell T775P2003/U Electronic Temperature Controller

SKU: 376232

$347.46/ea
Save 58% · Retail: $833.90

  Available to Ship in 4-5 weeks


Ships From Price Qty
Order From Manufacturer
Available to Ship in 4-5 weeks
$347.46/ea

About the Honeywell T775P2003

Honeywell T775P2003/U Electronic Temperature Controller. The T775 electronic remote temperature controllers are the next generation of commercial and agricultural controls. Capable of remote sensing of temperature and providing switched and/or proportional outputs to various types of loads.

Product Details

Product: Controller
Manufacturer: Honeywell
Product Collection: Electronic
Mpn # T775P2003
Weight 1.75 lbs.

Product Features

  • Staging controller for applications where electronic accuracy and remote sensing of temperature is required.
  • Ambient-- -40 C to 52 C @ 50 Hz; -40 C to 60 C @ 60 Hz
  • Special Boiler with Reset-NEMA 1
  • relay w/ RESET
  • Electronic Series 90; 4-20 mA; 0-10 Vdc; 2-10 Vdc
  • 4 SPDT
  • AC-- 30 Vac RMS; 1.5 A steady 3A inrush P.F. 0.45 N.C.; 20 Vac RMS; 100 mA minimum load on N.O. and N.C. contacts, DC-- 1 mA at 100 mV DC minimum load
  • 24 Vac-- 10.0A resistive; 120 Vac-- 1/2 hp; 9.8 AFL, 58.8 ALR, 125 VA Pilot Duty; 240 Vac-- 1/2 hp; 4.9 AFL, 29.4 ALR, 125 VA Pilot Duty
  • 3
  • 1097 ohms PTC at 77 F (25 C)
  • 50021579-001 (3)
  • 8 5/32 in. high x 4 13/32 in. wide x 2 15/16 in. deep
  • Up to 1,000 ft
  • up to 304 m
  • 1/4 in. diameter x 2 in. long
  • 6.35 mm diameter x 50.8 mm
  • 3.6 C
  • F
  • 1 F to 150 F
  • 0.5 C to 66 C
  • Add 1 or 2 T775Ss (4 relays ea)
  • Yes
  • 207.1 mm high x 112.1 mm wide x 74 mm deep
  • 50 Hz; 60 Hz
  • Approved
  • 24 Vac or 120/240 Vac
  • -40 C to 120 C
  • -40 F to 248 F
  • Ambient-- -40 F to 140 F @ 60 Hz; -40 F to 125 F @ 50 Hz
