Honeywell VGF21ES40 2-Way 4 Inch Flanged Globe Valve

SKU: 379715

Cargo Shipping Only
Save 58% · Retail: $2,579.05

In Stock and Ready to Ship

Ships From Price Qty
Illinois Warehouse
Ships in 4-6 Days
$1,089.65/ea 1
Long Island Warehouse
Ships in 1-4 Days
$1,089.65/ea 1
Order From Manufacturer
Available to Ship in 3-4 weeks

About the Honeywell VGF21ES40

Honeywell VGF21ES40 2-Way 4 Inch Flanged Globe Valve. This valve is also called a mixing valve and it’s an ANSI class 125 cast iron bodies with flanged end connections with linear flow. It is used for 2-position or modulating control of steam, hot water, or chilled water-glycol solutions up to 50 percent concentration, in closed loop heating, ventilation and air conditioning (HVAC) systems. This valve also has an accurate positioning with equal percentage and linear flow characteristics to ensure precise temperature control. It is made of stainless steel trim standard for long life span. This Honeywell Honeywell VGF21ES40 2-Way 4 Inch Flanged Globe Valve has a self-adjusting packing, steam inlet pressure up to 125 psig and 353 F maximum temperatures. It is a universal bonnet for direct-coupled electric and pneumatic actuators for easy mounting, or linkage coupled modutrol™ motors and MN/MS series direct coupled actuators. The Honeywell VGF21ES40 2-Way 4 Inches Flanged Globe Valve has a face-to-face flange dimensions per ANSI/ISA S75.03 standard and a constant total flow throughout full plug travel (3-way bodies). It offers best in class size, CV range and close-off pressure, and a precise control for any application. Honeywell was known for its Leadership, invention and manufacturing technologies. Honeywell have unrelenting focus on performance, quality, delivery, value and technology in everything they make and do.

Product Details

Product: Globe
Manufacturer: Honeywell
Style: 2 Way
Color: Blue
Connection Type: Flanged
Stem Size: 1 1/2" - 2 1/2"
Mpn # VGF21ES40
Shipping Dimensions 13.0" x 11.0" x 9.0"
Weight 256.00 lbs.

Product Features

  • 13-7/8 in. lenght x 9 in. height x 11-3/4in.H
  • DN100
  • -7 C to +120 C, steam 180 C
  • 20 F to 250 F, steam 353 F
  • 1-7/8 in.
  • 34 psi
  • 234 kPa
  • 150 Cv
  • 129 kvs
  • Stem down to close
  • Globe Valve
  • 352 mm height x 229 mm width x 300 mm height
  • Chilled or hot water with up to 50% Glycol or Steam. Not for use with fuels.
  • Cast Iron ASTM A126 Class B
  • Stainless Steel
  • Equal Percentage
  • Must be purchased separately
  • Meets ANSI 125 Standard
  • 125
  • 1 1/2 in.
  • 38 mm
  • 47.6 mm
  • 175 psig
  • Spring-loaded PTFE cone rings
  • 0.05% of Cv
  • 1206 kappa
  • ML6421B; ML7421B; Q5001/Modutrol IV Motor; MP953
  • Direct acting
  • Flanged
  • Two-way
  • 4 in.
